Internal Gear Pumps QXV
(for low-viscosity fluids)

The QVX is an internal gear pump for low viscosity. It can develope pressures of 300 bar with high efficiency at viscosities of around 1 mm²/s. The QXV is beeing used with great success to pump aviation jet fuels, paraffin oil/kerosene, brake fluids, Pentosin and HFA fluids.

Advantages

• Very low noise levels
• 300 bar can be developed
• Outstanding efficiencies
• Long service life
• Low pump wear
• Low sceptibility to cavitation
• Good emergency running

Technical data

Unit

Value

Continuous pressure up to

Peak pressure

Effective displacement

Speed max.

Viscosity range

Volumetric efficiency

bar

bar

cm³/rev

rpm

mm²/s

%

25 - 250

300

5 - 500

3600

0.8 - 10

>95

Applications

• Test rigs for diesel injektion nozzles
• Test rigs for testing Jet A1/ fuel controllers for aircraft turbines
• Rolling mills
• Fuel pumps for gasturbines
• Welding machines
• Inbrication pump for spindle bearings
