Saving Energy -
The Right Way!
We‘ll show you how this is possible
even with your mobile equipment
Energy, by definition "the ability to perform mechanical work", is limited.
Why, then, do we waste it unnecessarily? Bucher Hydraulics, specialists
in safety technologies for mobile machines, offers an efficient but
simple-to-use regenerative load-control and safety valve, which pays for
itself in no time at all.
CINDY-REG regenerative load-control valve
Costs are lowered
Costly tank lines, leak-prone fittings and complex main manifold
blocks are eliminated. With our valve, the entire regeneration
takes place right at the cylinder.
Up to 25% energy saving can be realized!
Customer feedback:
„As well as helping us to win a higher energy-efficiency
label, this technology gives us an effective cost saving -
which is also in our customers‘ interests!"
Function
The oil flowing back from the actuator enters the safety valve
and is then fed directly into the opposite line. If the control valve
is not operated, the remaining oil flows back to tank with no
back pressure. Energy is saved, because no pump flow is
needed for this function.
Construction
As well as the main elements, such as the zero-leakage
control assembly and direct-acting pressure relief function,
the valve offers an integral balance valve for tandem
applications. It is also possible to bleed air from the system
from outside.
Benefit
• Lower energy consumption
• Improved efficiency
• Meets the requirement of ISO 8643
• Leak-free load holding
• No separate tank line
Series
Nominal size
Mounting
Max. pump pressure
Max. load pressure
Max. flow rate
During the design phase, we paid special attention to
the conditions typically found in mobile machines.
The compactness and the direct mounting meet all
the requirements.
Important Features
-
Valve opening action is two-stage and load-independent
-
Directly operated, fast-acting secondary pressure relief
-
Integral air-bleeding of pilot circuit
Your Benefits
- Unaffected by load- and return-pressures
- Low-noise control spool
- Load-assisted closing function, high shut-off reliability
- Various control covers for perfect customization
