Full Catalog: Logic and Compensator Elements

Technical Data

Symbol Type Flow
GPM
Size
SAE
Data sheet

This unit is a direct acting, screw in cartridge style, spool type, hydraulic directional logic element, with multi-functional potential when used with other directional, pressure or flow control devices.

LCEF-08-A 10 08 LCEF-08-A_520-P-070110-en
LCEF-10-A 20 10 LCEF-10-A_520-P-070120-en
LCEF-12-A 36 12 LCEF-12-A_520-P-070130-en
 This unit is a direct acting, screw in cartridge style, spool type, hydraulic directional logic element, with multi-functional potential when used with other directional, pressure or flow control devices.
LCEF-08-C 10 08 LCEF-08-C_520-P-070310-en
LCEF-10-C 20 10 LCEF-10-C_520-P-070320-en
LCEF-12-C 36 12 LCEF-12-C_520-P-070330-en

This unit is a direct acting, screw in cartridge style, spool type, hydraulic directional logic element, with multi-functional potential when used with other directional, pressure or flow control devices.

LCEF-08-D 10 08 LCEF-08-D_520-P-070410-en
LCEF-10-D 20 10 LCEF-10-D_520-P-070420-en
LCEF-12-D 36 12 LCEF-12-D_520-P-070430-en

This unit is a direct acting, screw in cartridge style, spool type, hydraulic directional logic element, with multi-functional potential when used with other directional, pressure or flow control devices.

LCEF-08-F 10 08 LCEF-08-F_520-P-070610-en
LCEF-10-F 20 10 LCEF-10-F_520-P-070620-en
LCEF-12-F 36 12 LCEF-12-F_520-P-070630-en

This unit is a direct acting, screw in cartridge style, spool type, pressure-compensating inline flow element, intended for use with a remote fixed or variable orifice to yield a two-port (inline-type), pressure-compensated, flow regulating hydraulic valve.

PCEI-08 6 08 PCEI-08_520-P-071110-en
PCEI-10 10 10 PCEI-10_520-P-071120-en
PCEI-12 24 12 PCEI-12_520-P-071130-en
PCEI-16 36 16 PCEI-16_520-P-071140-en

This unit is a direct acting, screw in cartridge style, spool type, pressure-compensating priority type flow element, intended for use with a remote fixed or variable orifice to yield a three-port (bypass-type), pressure-compensated, flow regulating hydraulic valve.

PCEB-08 8 08 PCEB-08_520-P-071510-en
PCEB-10 18 10 PCEB-10_520-P-071520-en
PCEB-12 32 12 PCEB-12_520-P-071530-en
PCEB-16 36 16 PCEB-16_520-P-071540-en

This unit is a direct acting, screw in cartridge style, spool type, priority on demand pressure compensated flow control element. This unit is used to provide a load sense steering first with the priority flow when the steering demands the flow and the amount it requires before any other function in the system. When the steering or any other priority functions are satisfied, only then the excess flow is diverted to the auxiliary port for other functions.

PODS-08 8 08 PODS-08_520-P-071610-en
PODS-10 16 10 PODS-10_520-P-071620-en
PODS-12 24 12 PODS-12_520-P-071630-en
PODS-16 36 16 PODS-16_520-P-071640-en
