Full Catalog: Solenoid Valves

Technical Data

Symbol Type Flow
GPM
Size
SAE
Data sheet

This unit is a normally closed, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-08-C6 5 08 EMDV-08-C6_520-P-100110-en
This unit is a normally closed, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.
EMDV-10-C1 8 10 EMDV-10-C1_520-P-100120-en
EMDV-12-C1 18 12 EMDV-12-C1_520-P-100130-en

This unit is a normally closed, two position, cartridge type, poppet type, pilot operated, screw in type, solenoid operated, directional control valve.

EMDV-08-C7 10 08 EMDV-08-C7_520-P-100210-en

This unit is a normally closed, two position, cartridge type, poppet type, pilot operated, screw in type, solenoid operated, directional control valve.

EMDV-10-C2 18 10 EMDV-10-C2_520-P-100220-en
EMDV-12-C2 36 12 EMDV-12-C2_520-P-100230-en
EMDV-16-C2 50 16 EMDV-16-C2_520-P-100240-en

This unit is a normally closed, two position, cartridge type, balanced poppet, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-08-C3 5 08 EMDV-08-C3_520-P-100310-en
EMDV-10-C3 6 10 EMDV-10-C3_520-P-100320-en

This unit is a normally closed, two position, cartridge type, poppet type, pilot operated, screw in type, solenoid operated, directional control valve.

EMDV-08-C8 10 08 EMDV-08-C8_520-P-100410-en

This unit is a normally closed, two position, cartridge type, poppet type, pilot operated, screw in type, solenoid operated, directional control valve.

EMDV-10-C4 20 10 EMDV-10-C4_520-P-100420-en
EMDV-12-C4 36 12 EMDV-12-C4_520-P-100430-en
EMDV-16-C4 50 16 EMDV-16-C4_520-P-100440-en
This unit is a normally open, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.
EMDV-08-O6 5 08 EMDV-08-O6_520-P-100510-en

This unit is a normally open, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-10-O1 8 10 EMDV-10-O1_520-P-100520-en
EMDV-12-O1 18 12 EMDV-12-O1_520-P-100530-en

This unit is a normally open, two position, cartridge type, poppet type, pilot operated, screw in type, solenoid operated, directional control valve.

EMDV-08-O7 10 08 EMDV-08-O7_520-P-100610-en

This unit is a normally open, two position, cartridge type, poppet type, pilot operated, screw in type, solenoid operated, directional control valve.

EMDV-10-O2 18 10 EMDV-10-O2_520-P-100620-en
EMDV-12-O2 36 12 EMDV-12-O2_520-P-100630-en
EMDV-16-O2 50 16 EMDV-16-O2_520-P-100640-en

This unit is a normally open, two position, cartridge type, poppet type, pilot operated, screw in type, solenoid operated, directional control valve.

EMDV-08-O8 10 08 EMDV-08-O8_520-P-100810-en

This unit is a normally open, two position, cartridge type, poppet type, pilot operated, screw in type, solenoid operated, directional control valve.

EMDV-10-O4 20 10 EMDV-10-O4_520-P-100820-en
EMDV-12-O4 36 12 EMDV-12-O4_520-P-100830-en
EMDV-16-O4 50 16 EMDV-16-O4_520-P-100840-en

This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-08-3J 5 08 EMDV-08-3J_520-P-101010-en

This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-10-3A 8 10 EMDV-10-3A_520-P-101020-en
EMDV-12-3A 12 12 EMDV-12-3A_520-P-101030-en
ESDV-12-3A 16 12 ESDV-12_520-P-106030-en

This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-08-3K 5 08 EMDV-08-3K_520-P-101110-en

This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-10-3B 8 10 EMDV-10-3B_520-P-101120-en
EMDV-12-3B 12 12 EMDV-12-3B_520-P-101130-en
ESDV-12-3B 16 12 ESDV-12_520-P-106030-en

This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-08-3L 5 08 EMDV-08-3L_520-P-101210-en

This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-10-3C 8 10 EMDV-10-3C_520-P-101220-en
EMDV-12-3C 12 12 EMDV-12-3C_520-P-101230-en
ESDV-12-3C 16 12 ESDV-12_520-P-106030-en
This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.
EMDV-10-3D 8 10 EMDV-10-3D_520-P-101320-en
EMDV-12-3D 12 12 EMDV-12-3D_520-P-101330-en
ESDV-12-3D 16 12 ESDV-12_520-P-106030-en

This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-10-3E 8 10 EMDV-10-3E_520-P-101420-en
This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.
EMDV-08-3N 5 08 EMDV-08-3N_520-P-101510-en

This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-08-3P 5 08 EMDV-08-3P_520-P-101610-en

This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-08-3R 5 08 EMDV-08-3R_520-P-101710-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-08-4J 5 08 EMDV-08-4J_520-P-102510-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-10-4A 8 10 EMDV-10-4A_520-P-102520-en
EMDV-12-4A 16 12 EMDV-12-4A_520-P-102530-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, normally closed selector valve.

EMDV-08-4K 5 08 EMDV-08-4K_520-P-102610-en
This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, normally closed selector valve.
EMDV-10-4B 8 10 EMDV-10-4B_520-P-102620-en
EMDV-12-4B 16 12 EMDV-12-4B_520-P-102630-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, normally open selector valve.

EMDV-08-4L 5 08 EMDV-08-4L_520-P-102710-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, normally open selector valve.

EMDV-10-4C 8 10 EMDV-10-4C_520-P-102720-en
EMDV-12-4C 16 12 EMDV-12-4C_520-P-102730-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, normally open selector valve.

EMDV-08-4N 5 08 EMDV-08-4N_520-P-102810-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-10-4D 8 10 EMDV-10-4D_520-P-102820-en
EMDV-12-4D 16 12 EMDV-12-4D_520-P-102830-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

EMDV-10-4E 8 10 EMDV-10-4E_520-P-102920-en
EMDV-12-4E 16 12 EMDV-12-4E_520-P-102930-en
This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.
EMDV-12-4F 20 12 EMDV-12-4F_520-P-103030-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, normally open selector valve.

EMDV-08-4M 5 08 EMDV-08-4M_520-P-103110-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, normally open selector valve.

EMDV-8-4P 5 08 EMDV-08-4P_520-P-103210-en

This unit is a three-way, three position, cartridge type, spool type, solenoid operated, directional control valve.

EMBV-08-3J 5 08 EMBV-08-3J_520-P-104110-en

This unit is a four-way, three position, cartridge type, spool type, direct acting, screw in type, solenoid operated, double coil, bidirectional, tandem center selector valve.

EMBV-08-4J 5 08 EMBV-08-4J_520-P-104210-en
EMBV-10-4J 9 10 EMBV-10-4J_520-P-104220-en

This unit is a four-way, three position, cartridge type, spool type, direct acting, screw in type, solenoid operated, double coil, bidirectional, open center selector valve.

EMBV-08-4K 5 08 EMBV-08-4K_520-P-104310-en
EMBV-10-4K 7 10 EMBV-10-4K_520-P-104320-en
This unit is a four-way, three position, cartridge type, spool type, direct acting, screw in type, solenoid operated, double coil, bidirectional, closed center selector valve.
EMBV-08-4L 5 08 EMBV-08-4L_520-P-104410-en
EMBV-10-4L 6 10 EMBV-10-4L_520-P-104420-en
This unit is a four-way, three position, cartridge type, spool type, direct acting, screw in type, solenoid operated, double coil, bidirectional, motor spool selector valve.
EMBV-10-4M 6 10 EMBV-10-4M_520-P-104520-en

This unit is a three-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

WKP32G / OLA1 13 08 / NG1 WKP32-1_400-P-120621-en
WKP32G / ONA3 4 08 / NG3 WKP32-3_400-P-120821-en
WK32G / O 8 08 / NG5 WK32-5_400-P-121180-en

This unit is a four-way, two position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

WKP42ALA1 13 08 / NG1 WKP42-1_400-P-120641-en
WKP42ANA3 4 08 / NG3 WKP42-3_400-P-120841-en

This unit is a four-way, three position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

WK43D 8 08 / NG5 WK43-5_400-P-121240-en

This unit is a four-way, three position, cartridge type, spool type, direct acting, screw in type, solenoid operated, directional control valve.

WK43G 8 08 / NG5 WK43-5_400-P-121240-en

This unit is a three-way, two position, cartridge type, poppet type, direct acting, screw in type, solenoid operated, directional control valve.

WS32GNA5 5.8 08 / NG5 WS32-5_400-P-121200-en
Coil Information

Square coil type "L" and "S"

Round coil type D 2.2"/.875"

Soft Shift Option

For selected push-type solenoid valves

Manual Over-Ride Button

For size 10-12-16 push-type solenoid valves
