Full Catalog: Relief Valves

Technical Data

Symbol Type Flow
GPM
Size
SAE
Data sheet

This unit is a direct acting, remote control for valves with low pilot flow, cartridge type, steel ball, low leakage, screw in type, adjustable, pressure control valve.

RVPD-08 2 08 RVPD-08_520-P-030110-en
RVPD-10 2 10 RVPD-10_520-P-030120-en
This unit is a differential area relief valve, cartridge type, direct acting, poppet type, low leakage, screw in type, adjustable, pressure control valve.
RVDA-08 10 08 RVDA-08_520-P-030210-en
RVDA-10 20 10 RVDA-10_520-P-030220-en

This unit is a pilot operated, balanced sliding spool, pressure relief, cartridge valve for accurate and smooth pressure regulation.

RVPS-08 15 08 RVPS-08_520-P-030310-en
RVPS-10 26 10 RVPS-10_520-P-030320-en
RVPS-12 60 12 RVPS-12_520-P-030330-en

This unit is a pilot operated, poppet type, adjustable, hydraulic pressure relief with free reverse flow, screw in cartridge valve.

RVPP-10 26 10 RVPP-10_520-P-030420-en
RVPP-12 60 12 RVPP-12_520-P-030430-en

This unit is a differential area, poppet type, bi-directional, adjustable, hydraulic pressure relief, cartridge valve.

RVBD-08 10 08 RVBD-08_520-P-030510-en
RVBD-10 20 10 RVBD-10_520-P-030520-en
RVBD-12 40 12 RVBD-12_520-P-030530-en

This unit is a direct acting relief valve, cartridge type, poppet type, low leakage, screw-in type, adjustable, pressure control valve.

RVDI-10 10 10 RVDI-10_520-P-030620-en

This unit is a pilot operated, sliding spool, pressure breaker relief valve, cartridge style, screw in type valve.

RVBS-10 25 10 RVBS-10_520-P-030720-en

This unit is a direct acting, screw in cartridge style, hydraulic 3-way, 2 position, unloading relief valve which can be dumped or unloaded via a remote pilot signal.

PUVA-10 1 10 PUVA-10_520-P-030820-en

This unit is a normally open, two position, cartridge type, spool type, pilot operated, screw in type, solenoid operated, hydraulic relief valve.

ESRV-10 26 10 ESRV-10_520-P-030920-en

This unit is a differential area relief valve, cartridge type, direct acting, poppet type, low leakage, screw in type, adjustable, pressure control valve.

CPRV-10 20 10 CPRV-10_520-P-031020-en
