Full Catalog: Flow Control Valves

Technical Data

Symbol Type Flow
GPM
Size
SAE
Data sheet

This unit is a screw in, cartridge type, non-compensated, adjustable, bi-directional needle flow control valve.

NFCV-08 10 08 NFCV-08_520-P-020110-en
NFCV-10 18 10 NFCV-10_520-P-020120-en
This unit is a screw in, cartridge type, non-compensated, adjustable, bi-directional fine adjustment needle flow control valve.
NFFC-10 8 10 NFFC-10_520-P-020020-en

This unit is a screw in, cartridge type, adjustable, poppet type, hydraulic flow control valve with or without free reverse flow check.

FCVL-08 10 08 FCVL-08_520-P-020210-en
FCVL-10 18 10 FCVL-10_520-P-020220-en
FCVL-12 36 12 FCVL-12_520-P-020230-en

This unit is a screw in, cartridge type, pressure compensated, fixed orifice, restrictive hydraulic flow control valve.

PCFC-08 6 08 PCFC-08_520-P-020310-en
PCFC-10 12 10 PCFC-10_520-P-020320-en
PCFC-12 24 12 PCFC-12_520-P-020330-en

This unit is a screw in, cartridge type, pressure compensated, fixed orifice, priority type hydraulic flow control valve.

BFCV-08 6 08 BFCV-08_520-P-020510-en
BFCV-10 12 10 BFCV-10_520-P-020520-en
BFCV-12 20 12 BFCV-12_520-P-020530-en
BFCV-16 30 16 BFCV-16_520-P-020540-en

This unit is a spool type, screw in cartridge style, flow divider/combiner valve.

FDCV-08 8 08 FDCV-08_520-P-021010-en
FDCV-10 16 10 FDCV-10_520-P-021020-en
FDCV-12 32 12 FDCV-12_520-P-021030-en

This unit is a spool type, screw in cartridge style, flow divider/combiner traction valve. This valve is used when hydraulic motors are used as drive motors on each side of a machine.

FDCT-08 8 08 FDCT-08_520-P-021110-en

This unit is a screw in, cartridge type, non-compensated, adjustable, bi-directional rotary flow control valve.

MRFC-10 18 10 MRFC-10_520-P-022020-en
