Full Catalog: Proportional Valves

Technical Data

Symbol Type Flow
GPM
Size
SAE
Data sheet

This unit is a screw in cartridge style, direct acting, sliding spool type, 4 way 3 position proportional directional control valve with floating center spool.

PDFC-10_4M 8 10 PDFC-10_520-P-113020-en

This unit is a screw in cartridge style, direct acting, sliding spool type, 4 way 3 position proportional directional control valve with closed center spool.

PDFC-10_4L 8 10 PDFC-10_520-P-113020-en

This unit is a electro-hydraulic, proportional, screw in cartridge style, direct acting, spool type, pressure reducing/relieving flow pressure control valve

EPRR-10 1 10 EPRR-10_520-P-110120-en
This unit is an electro-hydraulic, proportional, screw in cartridge style, pilot operated, sliding spool type, high pressure reducing and relieving control valve.
EPRT-08 7 08 EPRT-08_520-P-110260-en
This unit is an electro-hydraulic, proportional, screw in cartridge style, pilot operated, sliding spool type, high pressure reducing and relieving control valve.
EPRS-10 12 10 EPRS-10_520-P-110220-en
EPRS-12 24 12 EPRS-12_520-P-110230-en

This unit is an electro-hydraulic, proportional, screw in cartridge style, pilot operated, sliding spool type, high pressure relief valve.

ERVP-10 25 10 ERVP-10_520-P-110320-en
ERVP-12 60 12 ERVP-12_520-P-110330-en

This unit is an electro-hydraulic, proportional, screw in cartridge style, direct acting, low flow, poppet type, high pressure relief valve.

ERVD-10 1 10 ERVD-10_520-P-110420-en

This valve is a cartridge style, electro-hydraulic, proportional, in-line (restrictive) type, pressure compensated, hydraulic flow control.

EPFI-10 8 10 EPFI-10_520-P-111020-en
EPFI-12 15 12 EPFI-12_520-P-111030-en

This valve is a cartridge style, electro-hydraulic, proportional, in-line (restrictive) type, pressure compensated, hydraulic flow control.

EPFC-16 20 16 EPFC-16_520-P-111040-en

This valve is a cartridge style, electro-hydraulic, proportional, priority (by-pass) type, pressure compensated, hydraulic flow control.

EPFB-10 8 10 EPFB-10_520-P-111520-en
EPFB-12 15 12 EPFB-12_520-P-111530-en

This valve is a cartridge style, electro-hydraulic, proportional, priority (by-pass) type, pressure compensated, hydraulic flow control.

EPFD-16 20 16 EPFD-16_520-P-111540-en

This unit is a cartridge style, electro-hydraulic, proportional, in-line (restrictive) type, hydraulic non-compensated flow control.

PFCV-10 16 10 PFCV-10_520-P-112020-en
PFCV-12 24 12 PFCV-12_520-P-112030-en
PFCV-16 36 16 PFCV-16_520-P-112040-en

This unit is a screw in cartridge style, direct acting, sliding spool type, 3 way proportional throttle valve.

MDR32GN 8 08 / NG5 MDR32G-5_400-P-618101-en

This unit is a screw in cartridge style, direct acting, sliding spool type, 4 way 2 position proportional directional control valve with closed center spool.

MDR42A 8 08 / NG5 MDR42AD-5_400-P-618201-en

This unit is a two-stage proportional throttle valve, screw-in cartridge type, with seat-valve shut-off.

MVRPSBA-2G 13 08 / NG5 MVRPSB-G-5_400-P-605101-en

This valve is an electro-hydraulic, proportional, in-line (restrictive) type, pressure compensated, hydraulic flow control.

PIFC-10 16 10 PIFC-10_520-P-112120-en
PIFC-12 24 12 PIFC-12_520-P-112130-en
PIFC-16 36 16 PIFC-16_520-P-112140-en

This valve is an electro-hydraulic, proportional, priority (by-pass) type, pressure compensated, hydraulic flow control.

PBFC-10 16 10 PBFC-10_520-P-112220-en
PBFC-12 24 12 PBFC-12_520-P-112230-en
PBFC-16 36 16 PBFC-16_520-P-112240-en
PWM-1400

Proportional Valve Driver (Block Mounted)

PWM-1401

Proportional Valve Driver (Coil Mounted)
