Full Catalog: Shuttle Valves

Technical Data

Symbol Type Flow
GPM
Size
SAE
Data sheet

This unit is a screw in, cartridge type, two ported with external third outlet port, two position, hydraulic shuttle valve.

BDSV-2-10 6 10 BDSV-10_520-P-040120-en
This unit is a screw in, cartridge type, three ported, two position, hydraulic shuttle valve.
BDSV-3-04 1.5 04 BDSV-04_520-P-040200-en
BDSV-3-08 3 08 BDSV-08_520-P-040210-en
BDSV-3-10 6 10 BDSV-10_520-P-040220-en

This unit is a screw in, cartridge type, three ported, two position, hydraulic shuttle valve.

HOSR-10 6 10 HOSR-10_520-P-040420-en

This unit is a direct acting, screw in cartridge style, spool type, hydraulic 3-way, 2-pos. directional shuttle valve, which may be used on a hydrostatic transmission to direct charge charge pump oil to heat exchanger or to tank.

HOSV-C-10 16 10 HOSV-10_520-P-040520-en

This unit is a direct acting, screw in cartridge style, spool type, hydraulic 3-way, 2-pos. directional shuttle valve, which may be used on a hydrostatic transmission to direct charge charge pump oil to heat exchanger or to tank.

HOSV-O-10 16 10 HOSV-10_520-P-040620-en

This unit is a screw in, cartridge type, four ported spool type, three position, spring centered, hydraulic brake release shuttle valve.

SDSV-08 5 08 SDSV-08_520-P-041010-en

This unit is a screw in, cartridge type, three ported spool type, three position, spring centered, hydraulic brake release shuttle valve.

SDSV-3A-10 24 12 SDSV-12_520-P-041130-en
