Analog Electronic Control Systems

Analog Electronic Control Systems

Proportional Amplifier ELSK 103

  • With one power output and two ON / OFF outputs
  • To drive one proportional valve and one ON / OFF directional valve
  • To drive two proportional solenoids and one ON / OFF directional valve
Supply Set value Output Adjustment Data sheet
12…30 V DC ON / OFF, control signal potentiometer prop. 2500 mA
on/off 3000 mA		 I min, I max ELSK103_100-P-700064-en

Proportional Amplifier ESSK 103

  • 1-channel for proportional valves  with one solenoid
  • With one control signal input andone power output
Supply Set value Output Adjustment Data sheet
12…30 V DC 0…5 V 500…2500 mA I min, I max ESSK103_100-P-700004-en

Proportional Amplifier ELSK 106

  • With one power output, switch ON / OFF and ramp
  • To drive one proportional solenoid, installed for example in instrument panel
Supply Set value Output Adjustment Data sheet
12…30 V DC ON / OFF
Control signal potentiometer		 2500 mA I min, I max ELSK106_100-P-700070-en

Proportionalverstärker ESSK106

  • 1-channel for proportional valves  with one solenoid
  • With one control signal input andone power output
Supply Set value Output Adjustment Data sheet
12…30 V DC 0…5 V 500…2500 mA I min, I max ESSK106_100-P-700008-en
