Full Catalog: Pressure Sequence Valves

Technical Data

Symbol Type Flow
GPM		 Size
SAE
 Data sheet Model data CAD (STEP/IGS)

This unit is a pilot operated, screw in cartridge style, poppet type with built in free reverse flow check, hydraulic pressure sequence valve.

 PSVP-10 20 10 PSVP-10_520-P-060720-en
This unit is a direct acting, screw in cartridge style, poppet type, adjustable, soft shift (shock free), hydraulic hi-lo pressure sequence valve.
 HLSV-10 20 10 HLSV-10_520-P-060220-en

This unit is a direct acting, screw in cartridge style, spool type, adjustable, soft shift (shock free), hydraulic hi-lo pressure sequence valve.

 HLSS-10 20 10 HLSS-10_520-P-060120-en

This unit is a pilot operated, screw in cartridge style, sliding spool type, adjustable, external pilot, hydraulic pressure sequence valve.

 PSXS-08 6 08 PSXS-08_520-P-060310-en
PSXS-10 12 10 PSXS-10_520-P-060320-en

This unit is a pilot operated, screw in cartridge style, sliding spool type, adjustable, internal pilot, hydraulic pressure sequence valve.

 PSOS-08 6 08 PSOS-08_520-P-060410-en
PSOS-10 12 10 PSOS-10_520-P-060420-en

This unit is a pilot operated, screw in cartridge style, sliding spool type, adjustable, internal pilot, hydraulic pressure sequence valve.

 PSCS-08 6 08 PSCS-08_520-P-060510-en
PSCS-10 12 10 PSCS-10_520-P-060520-en

This unit is a pilot operated, screw in cartridge style, poppet type with built in free reverse flow check, hydraulic pressure breaker/sequence valve.

 PBVP-10 20 10 PBVP-10_520-P-061120-en

This unit is a pilot operated, screw in cartridge style, sliding spool type, adjustable, external pilot, hydraulic pressure breaker/sequence valve.

 BSXS-08 6 08 BSXS-08_520-P-061310-en
BSXS-10 12 10 BSXS-10_520-P-061320-en

This unit is a pilot operated, screw in cartridge style, sliding spool type, adjustable, internal pilot, hydraulic pressure breaker/sequence valve.

 BSOS-08 6 08 BSOS-08_520-P-061410-en
BSOS-10 12 10 BSOS-10_520-P-061420-en

This unit is a pilot operated, screw in cartridge style, sliding spool type, adjustable, internal pilot, hydraulic pressure breaker/sequence valve.

 BSCS-08 6 08 BSCS-08_520-P-061510-en
BSCS-10 12 10 BSCS-10_520-P-061520-en
